EGS-69
Gastrointestinal and Colono VideoScope
Gastrointestinal & Colono VideoScope
|
Item/Model |
Gastrointestinal video scope |
Colonovideoscope |
|
Field of view |
120' Forward viewing |
120* Forward viewing |
|
Depth of View Field |
5mm-100mm Fixed Focus |
5mm- 100mm Fixed Focus |
|
Range of Tip Bending |
Up 210' . down 100' |
Up 180* . down 150* |
|
Outer Diameter of Distal End |
Φ 9.8mm/0 9mm |
Φ 13.2mm/0 14.3mm |
|
Outer Diameter of Insertion |
Φ 9.8mm/0 9mm |
Φ 12.8mm/0 13.7mm |
|
Inner Diameter of Instrument |
Φ 2.8mm/0 2.2mm |
Φ 3.8mm/0 4.2mm |
|
Working Length |
1025mm/1025mm |
1300mm/1500mm/1680mm |
|
Waterproof |
Standard Configurations:
Gastrointestinal and Colono VideoScope main unit*1;
Leak detection cover*1;
Plug the mouth cap*5;
Hand pressure leak detector*1;
Cleaning brush*1;
Biopsy forceps* 1;
Water bottle assembly*1;
Mouth pad*2;
Technical Instructions*1;
User Manual*1;
Carton box*1
